Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-191
8_
8.14.2.1 ETH_Link_Config
FB/FC
Explanation Applicable model
FB
ETH_Link_Config is used for configuring parameters for MODBUS TCP
data exchange at the LAN2 port of the motion controller.
DVP15MC11T
DVP15MC11T-06
ETH_Link_Config
Execute
ETH_Link_Config_instance
LinkNum
Done
Error
ErrorID
EnableLink
SlaveNodeID
ObjType
En_FunCode17
Write_Buffer_Address
Write_Destination_Address
Write_Length
Read_Buffer_Address
Write_Buffer_Address_Offset
Read_Buffer_Address_Offset
Read_Destination_Address
Read_Length
Read_FunCode
Timeout
SlaveIP_segment1
SlaveIP_segment2
SlaveIP_segment3
SlaveIP_segment4
 Input Parameters
Parameter name Function Data type
Valid range
(Default)
Validation timing
Execute
The instruction is
executed when Execute
changes from FALSE to
TRUE.
BOOL
TRUE or FALSE
（FALSE）
LinkNum
Set the number of
MODBUS TCP data
exchange
UINT
1~16
（0）
When Execute
changes from
FALSE to TRUE
EnableLink Enable or disable the link BOOL
TRUE or FALSE
（FALSE）
When Execute
changes from
FALSE to TRUE
SlaveIP_segment1
Set the first segment of
the target IP address
USINT
0~255
（0）
When Execute
changes from
FALSE to TRUE
SlaveIP_segment2
Set the second segment
of the target IP address
USINT
0~255
（0）
When Execute
changes from
FALSE to TRUE
