6.7 Ethernet Communication Port
6.7.1 Function that Ethernet Communication Port Supports
 the 

Both of the two Ethernet ports can be used to download configuration files, execution files and CAM files. They
also support automatic jumper function and users do not need to additionally select wire jumper when one of
Ethernet ports is connected to the computer or switchboard. Besides, they can automatically detect the
transmission speed of 10Mbps and 100 Mbps as well.
                 the 

Both of the two Ethernet ports support Modbus protocol. LAN1 port can work as a slave only and LAN2 port
can work as a master or a slave. LAN2 supports EtherNFor more

Item
LAN1
LAN2
Communication protocol MODBUS TCP
MODBUS TCP, Socket,
EtherNet/IP
MODBUS TCP
Connections (Server)
16
16
Connections (Client)
0
Socket
TCP connections
0 8
UDP connections
EtherNet/IP
Device type
Adapter
Adapter
CIP_IO
Connection
CIP connections
Unsupported
8
TCP connections
16
Interval time for sending
messages
(RPI)
5ms~1000ms
Maximum data size per
message
200bytes
CIP_Explicit
Message
Class 3
(Connected Type)
Unsupported
8
UCMM
(Non-Connected Type)
16
Supports CIP objects
Identity, Message
Router, Assembly,
Connection Manager,
Port, TCP/IP interface,
Ethernet link, Vendor
specific


