DVP-15MC Series Motion Controller Operation Manual
8-308
_8
FB/FC
Explanation Applicable model
FB
The Left_Manage instruction is used to enable or disable the function of
the left-side module device mapping.
DVP15MC11T
DVP15MC11T-06
Left_Manage_instance
Left_Manage
LeftOpened
Valid
Enable
Open
 Input Parameters
Parameter name Function Data type
Valid range
(Default)
Validation
timing
Enable
The instruction is executed when
Enable changes from FALSE to
TRUE.
BOOL
TRUE or FALSE
（FALSE）
-
Open
Enable the function of the left-
side module device mapping.
BOOL
TRUE or FALSE
（FALSE）
When
Enable
changes to
TRUE
 Output Parameters
Parameter name Function Data type Valid range
Valid
TRUE when the output of the instruction is valid. BOOL
TRUE / FALSE
LeftOpened
TRUE when the function of the left-side module device
mapping is enabled.
BOOL TRUE / FALSE
 Output Update Timing
Parameter Name Timing for changing to TRUE Timing for changing to FALSE
Valid
 When Enable changes to TRUE.
 When Enable changes from
TRUE to FALSE
LinkOpened
 When Enable changes to TRUE and Open
changes to TRUE.
 When Enable changes from
TRUE to FALSE
 When Open changes from TRUE
to FALSE
