Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-147
8_
FB/FC
Explanation
Applicable model
FC
LIMIT is used for limiting the output value within the zone between the
specified minimum and maximum values.
DVP15MC11T
DVP15MC11T-06
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
MN
Minimum
value
Input Minimum value
Depends on the data type of the
variable that the input parameter is
connected to.
In Data to limit Input Data to limit
Depends on the data type of the
variable that the input parameter is
connected to.
MX
Maximum
value
Input Maximum value
Depends on the data type of the
variable that the input parameter is
connected to.
Out
Processing
result
Output Processing result
Depends on the data type of the
variable that the output parameter is
connected to.
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD
DWORD
LWORD
USINT
UINT UDINT ULINT SINT INT DINT LINT REAL
LREAL
TIME
DATE
TOD
DT
STRING
MN
● ● ● ● ● ● ● ● ● ● ● ● ● ●
In
● ● ● ● ● ● ● ● ● ● ● ● ● ●
MX
● ● ● ● ● ● ● ● ● ● ● ● ● ●
Out
● ● ● ● ● ● ● ● ● ● ● ● ● ●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data
type.
 Function Explanation
 LIMIT instruction limits the value within range between MN and MX and the result is output to Out.
The value of In
The value of Out
In < MN
MN
MN ≤ In ≤MX
In
MX < In
MX
LIMIT
EN ENO
MN Out
MX
In
