DVP-15MC Series Motion Controller Operation Manual
8-148
_8
 The instruction allows input parameters MN, In and MX to connect the variables of different data
types. When MN, In and MX are the variables of different data types, the calculation is performed
with the data type which can contain the range of the values of MN, In and MX. For example, if the
data type of MN is INT and the data types of In and MX are DINT, the data type of Out is DINT.
 The instruction allows the input parameters and the output parameter to connect the variables of
different data types. But the length of the data type of the output variable must contain the length of
the variables that the input parameters In0 ~ InN connect. Otherwise, an error will occur during the
compiling of the software.
 Precautions for Correct Use
 The input variables are not allowed to omit. An error will occur during the compiling of the software
if the input variables are omitted. But the output variable is allowed to omit.
 Programming Example
 The data types of LIMIT_MN, LIMIT_In and LIMIT_MX are UINT, UINT and DINT and the data type
of Out1 is DINT. When LIMIT_EN is TRUE, the value of Out1 is 50 if the values of LIMIT_MN,
LIMIT_In and LIMIT_MX are 1, 50 and 100 as shown in the following table Variable 1. If the values
of LIMIT_MN, LIMIT_In and LIMIT_MX are 2, 200 and 100, the value of Out1 is 100 as shown in
the following table Variable 2. If the values of LIMIT_MN, LIMIT_In and LIMIT_MX are 50, 10 and
100, the value of Out1 is 50 as shown in the following table Variable 3.
 Variable 1
Variable name
Data type
Current value
LIMIT_EN
BOOL
TRUE
LIMIT_MN
UINT
1
LIMIT_In
UINT
50
LIMIT_MX
DINT
100
Out1
DINT
50
 Variable 2
Variable name
Data type
Current value
LIMIT_EN
BOOL
TRUE
LIMIT_MN
UINT
2
LIMIT_In UINT 200
LIMIT_MX
DINT
100
Out1
DINT
100
 Variable 3
Variable name
Data type
Current value
LIMIT_EN BOOL TRUE
LIMIT_MN
UINT
50
LIMIT_In
UINT
10
LIMIT_MX DINT 100
Out1
DINT
50
 The program
1
LIMIT
EN ENO
MN Out
MX
In
LIMIT_EN
LIMIT_MN
LIMIT_MX
LIMIT_In
Out1
