Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-221
8_
8.14.2.11 ETH_Socket_Receive
FB/FC
Explanation
Applicable model
FB ETH_Socket_Receive is used for receiving Socket data.
DVP15MC11T
DVP15MC11T-06
ETH_Socket_Receive
Execute
ETH_Socket_Receive_instance
Abort
Done
Received
Receiving
SocketNum
ReceiveMode
DataSaveMode
Receive_Buffer_Address
Receive_Length
Received_Length
Busy
Active
Aborted
Error
ErrorID
 Input Parameters
Parameter name Function Data type
Valid range
(Default)
Validation timing
Execute
The instruction is
executed when Execute
changes from FALSE to
TRUE.
BOOL
TRUE or FALSE
(FALSE)
Abort
Abort the instruction
execution.
BOOL
TRUE or FALSE
(FALSE)
SocketNum
Specify the number of the
Socket.
USINT
1~8
(0)
When Execute
changes from
FALSE to TRUE
ReceiveMode
Set the mode to receive
data.
0：Keep receiving data
1：Only receive one
piece of data
USINT
0, 1
(0)
When Execute
changes from
FALSE to TRUE
DataSaveMode
Set the mode to save
data.
0：Splicing
1：Covering
USINT
0, 1
(0)
When Execute
changes from
FALSE to TRUE
Receive_Buffer_Ad
dress
Specify the start register
for storing the received
data.
USINT
%MB0~%MB65
535
When Execute
changes from
FALSE to TRUE
Receive_Length
Set how many Bytes of
data to be received.
UINT
0~200
(200)
When Execute
changes from
FALSE to TRUE
