Delta DVP-15MC Series User Manual

DVP-15MC Series Motion Controller Operation Manual
8-192
_8
Parameter name Function Data type
Valid range
(Default)
Validation timing
SlaveIP_segment3
Set the third segment of
the target IP address
USINT
0~255
（0）
When Execute
changes from
FALSE to TRUE
SlaveIP_segment4
Set the fourth segment of
the target IP address
USINT
0~255
（0）
When Execute
changes from
FALSE to TRUE
SlaveNodeID
Set the node ID of the
MODBUS slave
USINT
0~255
（0）
When Execute
changes from
FALSE to TRUE
ObjType
Set the type of slave
registers to be read and
written.
0：Word register
1：Bit register
USINT
0~1
（0）
When Execute
changes from
FALSE to TRUE
En_FunCode17
Set the function code 17
to be used or not.
BOOL
TRUE or FALSE
（FALSE）
When Execute
changes from
FALSE to TRUE
Write_Buffer_Address
Specify the starting
register of the master
where data to be sent are
stored.
UINT
%MW0~%MW32
767
%QW0~%QW63
When Execute
changes from
FALSE to TRUE
Write_Buffer_Address
_Offset
Set the offset of the
starting register of the
master sending data.
The setting value 1
means the offset is 1 word
if data are written to the
word registers of the
slave.
The setting value 1
means the offset is 1 bit if
data are written to bit
registers of the slave.
USINT
0~255
（0）
When Execute
changes from
FALSE to TRUE
Write_Destination_Add
ress
Specify the starting
address of the registers of
the MODBUS slave
receiving the data from
the master
UINT
16#0~16#FFFF
（0）
When Execute
changes from
FALSE to TRUE
Write_Length
The length of data to be
written
UINT
Word register:
0~100
Bit register:
0~256
Word register or
bit register can be
set via the value
of ObjType
（0）
When Execute
changes from
FALSE to TRUE
Read_Buffer_Address
Specify the starting
UINT
%MW0~%MW32
When Execute
