Chapter 11 Motion Control Instructions

11-43

 Programming Example 2

The example is shown below when MC_MoveRelative which is being executed is aborted.

1. The variables and program

Variable name

Data type

Initial value

Pwr

MC_Power

Axis1

USINT

Pwr_En

BOOL

FALSE

Pwr_BM MC_Buffer_Mode 0

Pwr_Sta BOOL

Pwr_Bsy BOOL

Pwr_Act

BOOL

Pwr_Err

BOOL

Pwr_ErrID

WORD

Rel1

MC_MoveRelative

Rel1 _Ex

BOOL

FALSE

Rel1 _BM

MC_Buffer_Mode

Rel1 _Done

BOOL

Rel1 _Bsy

BOOL

Rel1 _Act BOOL

Rel1 _Abt BOOL

Rel1 _Err BOOL

Rel1 _ErrID

WORD

Rel2

MC_MoveRelative

Rel2 _Ex

BOOL

FALSE

Rel2 _BM

MC_Buffer_Mode

Rel2 _Done

BOOL

Rel2 _Bsy

BOOL

Rel2 _Act

BOOL

Rel2 _Abt BOOL

Rel2 _Err BOOL

Rel2 _ErrID

WORD
