3 • Configurations
Doc. 065031-04 1/08 107
Figure 3-2. Reagent-Free IC (RFIC)
Pump (front view)
To the pump inlet via the pump rear chase
Deionized
Water
EG
(left side view)
DC (front view)
To Waste
EGC
IN
OUT
CR-TC
Eluent
Eluent
In
Out
Regen
Out
Regen In
From the suppressor Regen Out via the DC rear chase
Pump inlet
On/Off
Valve
Seal
Wash
Pump
To waste
Eluent In Regen In
Regen Out Eluent Out
Cell In
Cell Out
Separator
Temp.
Stabilizer
(1)
L
L
S
W
P
C
(2)
(3)
(4)(5)
(6)
To AS/Waste
Guard
From AS
RFIC
Eluent Degasser
Eluent
In
Eluent
Out
Regen
In
Regen
Out
Mixer
Backpressure
Device
Piston
Seal
Wash
(pump not to scale)
To the CR-TC Regen In via the EG rear chase
