Doc. 065031-04 1/08 327
TC Service
9.25 Replacing Tubing and Fittings
The TC is plumbed with the tubing and fittings listed below.
Use double-cone 10-32 ferrule fittings (P/N 043276) and 10-32 bolts
(P/N 043275) for all tubing connections. For tightening requirements, refer to
Installation of Dionex Liquid Line Fittings (Document No. 031432). The manual
is on the Dionex Reference Library CD-ROM (P/N 053891).
Use a tubing cutter to cut tubing to the required length. Make sure the cut is at a
right angle to the length of the tubing and there are no nicks or burrs on the end. A
tubing cutter (P/N 049584) is included in the DC Ship Kit (P/N 062614, dual; P/N
063408, single). Refer to the instructions provided with the cutter.
To avoid injury, wait for the TC to cool down before opening the door
or performing any maintenance or service procedures.
Afin d'éviter toute brûlure, laisser refroidir le compartiment thermique
avant d'ouvrir la porte ou d'effectuer des opérations de maintenance.
Um Verletzungen zu vermeiden, warten Sie bitte, bis der TC abgekühlt
ist, ehe Sie die Tür öffnen bzw. Wartungs oder Servicearbeiten
durchführen.
Tubing Size and Type Color P/N Used For
0.125-mm (0.005-in) ID PEEK Black 052310 Standard bore system
connections
0.25-mm (0.010-in) ID PEEK Red 052306 Microbore system
connections
10-mm (0.39-in) ID polyethylene Colorless 055075 Waste line
