Dionex ICS-3000 - Reaction Coil Heater

ICS-3000 Ion Chromatography System
78 Doc. 065031-04 1/08
2.17.4 RCH-1 Reaction Coil Heater
The RCH-1 Reaction Coil Heater (P/N 061746) can hold up to two
reaction coils. The heater has an operating temperature range of from 5 °C
above the temperature of the upper compartment up to 80 °C.
Commands for heater control can be included in a program (see
Figure 2-43
) for automated control, or the heater can be controlled
manually from the DC Control panel (see Figure 2-42
).
Figure 2-43. Program Wizard DC Options Page
