Dionex ICS-3000 - Changing the Main Power Fuses

ICS-3000 Ion Chromatography System
334 Doc. 065031-04 1/08
9.29 Changing the Main Power Fuses
1. Press the POWER button on the front of the TC for 2 seconds to turn off the
power.
2. Disconnect the main power cord from both its source and from the TC rear
panel.
3. The fuse cartridge is located next to the main power switch (see Figure 9-48
).
Use a small screwdriver to remove the fuse cartridge.
4. Replace the two fuses with new 2 A IEC 60127-2 time lag fuses
(P/N 954776). Dionex recommends always replacing both fuses.
5. Reinstall the fuse cartridge.
6. Reconnect the main power cord and turn on the power.
HIGH VOLTAGE—Disconnect the main power cord from its source and
also from the rear panel of the TC.
HAUTE TENSION—Débranchez le cordon d'alimentation principal de
sa source et du panneau arrière du TC.
HOCHSPANNUNG—Ziehen Sie das Netzkabel aus der Steckdose und
der Netzbuchse auf der Rückseite des TC.
Figure 9-48. TC Fuse Cartridge
Fuse Cartridge
