EG Service
9.10 Replacing Tubing and Fittings
The EG is plumbed with the tubing and fittings listed below.
• Use 1/8-in fittings (P/N 052267) and ferrules (P/N 048949) for connections to
the suppressor
REGEN OUT port and the eluent reservoir.
• Use double-cone 10-32 ferrule fittings (P/N 043276) and 10-32 bolts
(P/N 043275) for all other tubing connections. For tightening requirements,
refer to Installation of Dionex Liquid Line Fittings (Document No. 031432).
The manual is on the Dionex Reference Library CD-ROM (P/N 053891).
Use a tubing cutter to cut tubing to the required length. Make sure the cut is at a
right angle to the length of the tubing and there are no nicks or burrs on the end. A
tubing cutter (P/N 049584) is included in the DC Ship Kit (P/N 062614, dual; P/N
063408, single). Refer to the instructions provided with the cutter.
Tubing Size and Type Color P/N Used For
0.25-mm (0.010-in) ID
PEEK
Black 042690 Connections from the EluGen
cartridge to the pump, from the
EluGen cartridge to the CR-
TC, from the RFIC Eluent
Degasser to the injection valve,
from the RFIC Eluent Degasser
to the eluent reservoir
3-mm (0.125-in) OD Teflon
tubing
Clear 014157 Connections from the RFIC
Eluent Degasser
REGEN IN to
the CR-TC, from the RFIC
Eluent Degasser
REGEN OUT
to waste
1.58-mm (0.062-in) ID
Polyurethane
Clear 047203 EluGen cartridge gas vent line
10-mm (0.39-in) ID
Polyethylene
Clear 055075 Drip tray waste line
