ICS-3000 Ion Chromatography System
326 Doc. 065031-04 1/08
10. Orient the cell assembly with the PEEK yoke knob (see Figure 9-34)
on the left and push the cell onto its mounting location in the DC
compartment.
11. Reconnect the two cables and the liquid lines.
12. Start the pump flow.
13. Wait until the pump pressure has stabilized (30 to 60 seconds) and
then turn on the cell voltage.
9.24.7 Replacing an ED Detector
1. Turn off the pump flow from the Control panel in Chromeleon or
Chromeleon Xpress or press
PUMP FLOW on the front of the pump.
2. Disconnect the ED from the Control panel in Chromeleon or
Chromeleon Xpress.
3. Press the
POWER button on the front of the DC to turn off the DC.
4. Open the DC upper door and disconnect the cell (see Section 9.24.1
).
5. Remove the cell from the detector.
6. Press the release lever located below the detector. The detector pops
out slightly from the DC compartment. Grasp the detector and pull
outward to remove the detector from the compartment.
7. Note the electrical plug on the back of the detector and the receptacle
on the inside of the DC.
8. Push the new detector into the opening in the DC and press firmly to
ensure the electrical connection is secure.
9. Reinstall the cell and reconnect the cell inlet and outlet lines and the
cables.
10. Turn on the DC power and restart the pump flow.
