9 • DC Service
Doc. 065031-04 1/08 325
5. To remove any particulate matter (such as salt crystals), rinse and dry
the reference electrode cavity.
6. Remove the O-ring from the bottom of the reference electrode (see
Figure 9-41
).
7. Slide the new O-ring (P/N 014067) onto the electrode.
8. To avoid any hydraulic pressure buildup when inserting the reference
electrode, make sure that fitting plugs are not installed on the cell
inlet and outlet fittings.
9. Screw the reference electrode into the cell body and tighten firmly
with your fingers.
Figure 9-40. Removing the Reference Electrode
Figure 9-41. Removing the Reference Electrode O-Ring
Unscrew the
reference
electrode
Reference
Electrode
O-Ring
