ICS-3000 Ion Chromatography System
30 Doc. 065031-04 1/08
2.6 EO (Optional)
The ICS-3000 Eluent Organizer (EO) holds eluent reservoirs in a liner that
contains spills and leaks. Up to two EOs can be installed on top of the DC. Each
EO accommodates up to four 1-liter or 2-liter reservoirs or up to two 4-liter
reservoirs. The EO is typically ordered configured with four 2-liter reservoirs
(P/N 062629).
All eluent reservoirs available for use with the DP/SP can be pressurized. If you
plan to pressurize the eluent reservoirs, an optional regulator kit is required. The
kit is available in two versions:
• When the DC is installed as the topmost module in the system, the EO
Regulator Kit (P/N 063493) is required. The kit includes a pressure regulator
and gauge assembly with four outputs (for connections to four eluent
reservoirs), as well as the tubing and connection fitting required.
• When the TC, ICS-Series Variable Wavelength Detector, or ICS-Series
Photodiode Array Detector is installed as the topmost module in the system,
the TC/VWD/PDA Regulator Bracket Kit (P/N 064792) is required. The kit
includes the EO Regulator Kit described above, as well as a right-angle
regulator bracket and mounting hardware. After attaching the bracket to the
TC or detector, you will mount the gas regulator assembly on the bracket.
If more reservoirs are required, order a second regulator (P/N 062345).
Setzen Sie den Eluentbehälter auf keinen Fall einem Druck über
0,07 MPa aus.
