Figure 9-4. DP/SP Primary Pump Head Assembly
Figure 9-5. DP/SP Secondary Pump Head Assembly
Piston
(P/N 062082)
Retainer for
Seal
(
P/N 062092
)
Piston
Seal Wash
Primary Pump Head
(P/N 062083)
Seal Wash Body
(P/N 062064)
Piston
Wash
Seal
Seal
(P/N 063382)
O-Ring
(P/N 040695)
Inlet Check Valve Assembly
(P/N 045722; includes check
valve body and cartridge)
Outlet Check Valve Assembly
(P/N 045721; includes check
valve body and cartridge)
Main Piston Seal
(P/N 064946)
Piston
(
P/N 062082
)
P
r
i
m
i
ng
V
a
l
ve
(P/N 062087)
Main Piston Seal
(P/N 064946)
Priming Valve Knob Seal
(P/N 063382)
Piston Seal Wash Seal
(P/N 063382)
Retainer for Seal Wash Seal
(P/N 062092)
Piston
Seal Wash Body
(P/N 062064)
O-Ring
(P/N 040695)
Secondary Pump Head
Pressure Transduce
r
Assembly
