ICS-3000 Ion Chromatography System
38 Doc. 065031-04 1/08
Fuse Holder, Main Power Switch, and Power Receptacle
The fuse cartridge contains two 2-amp slow-blow fuses (P/N 954773). For
instructions on how to change the fuses, see Section 9.16
.
The rear panel power switch is the main power switch for the EG. Turn on the
main power switch before initial operation and leave it on unless instructed to turn
it off (for example, before performing a service procedure).
NOTE For routine on/off control, use the POWER button on the
front of the EG (see Figure 2-7
). To turn off the EG,
press and hold the
POWER button for 2 seconds.
The power cord plugs into the IEC 320 three-prong receptacle.
Tubing Chase
The tubing chase routes tubing from the front of the EG, through the interior of
the module, and to the rear panel.
Vent, Suppressor, and Drain Lines
• The gas vent line (clear tubing) discharges the electrolysis gas (H
2
or O
2
) that
is vented from the electrolyte reservoir of the EluGen cartridge.
• The lines exiting the tubing chase (white tubing) are for connecting the
REGEN IN port on the CR-TC or EPM Electrolytic pH Modifier to the REGEN
OUT port on the suppressor.
• The drip tray drain port removes any liquid that collects in the drip tray in the
bottom of the EG. A clear corrugated tubing line is connected to this port
during installation.
The power supply cord is used as the main disconnect device. Make
sure the socket-outlet is located near the EG and is easily accessible.
Le cordon d'alimentation principal est utilisé comme dispositif
principal de débranchement. Veillez à ce que la prise de base soit
située/installée près du module et facilement accessible.
Das Netzkabel ist das wichtigste Mittel zur Stromunterbrechung.
Stellen Sie sicher, daß sich die Steckdose nahe am Gerät befindet und
leicht zugänglich ist.
