ICS-3000 Ion Chromatography System
42 Doc. 065031-04 1/08
NOTE The VALVE 1 and VALVE 2 buttons can be enabled
and disabled in Chromeleon or Chromeleon Xpress.
When disabled, the valve can be controlled only
from the software. To enable or disable a button,
open the Commands dialog box (press F8) and select
the Valve1Button (or Valve2Button) command in
the list of commands for the DC.
VALVE 1 LOAD
VALVE 2 LOAD
VALVE 1 INJECT
VALVE 2 INJECT
Use the VALVE 1 and VALVE 2
buttons to manually switch the
position of the DC injection valves.
The LEDs indicate whether the
valve is in the Load or Inject
position.
Valve error. See Section 8.25
for troubleshooting.
POWER
Use this POWER button for routine
on/off control of the DC. When the
power is on, this LED is lighted. To
turn off the DC, press and hold this
POWER button for 2 seconds.
Note: The main power switch is on
the DC rear panel.
Does not flash.
Button/LED Label If the LED Is On If the LED Is Flashing
