IMS.OM.002949.DRM Page 31 of 310 Version 1.4
Doremi Labs
SDI-A/SDI-B
● 3G-SDI — support is forthcoming, Q3 2014
● Used for Dual Projector setups
● Chase Mode
● Alternative Content Inputs
GPI
● General Purpose Input for Automation Interface
● RJ-45 Connector
Pin #
Signal
1
GPI 0+
2
GPI 0-
3
GPI 1+
4
GPI 2+
5
GPI 2-
6
GPI 1-
7
GPI 3+
8
GPI 3-
GPO
● General Purpose Output for Automation Interface
● RJ-45 Connector
Pin #
Signal
1
GPO 0
2
GPO 1
3
GPO 2
4
GPO 4
5
GPO 5
6
GPO 3
7
+5 VDC
8
Ground
AES-OUT 1-8
● Digital Audio Channels 1 - 8 Output
● RJ-45 Connector
Channels 1-8
Signal
1
Channel 1 & 2 plus
2
Channel 1 & 2 minus
3
Channel 3 & 4 plus
4
Channel 5 & 6 plus
5
Channel 5 & 6 minus
6
Channel 3 & 4 minus
7
Channel 7 & 8 plus
8
Channel 7 & 8 minus
