4-34

Connectrix DS-32M2 User Guide

Monitoring and Managing the Switch

Information on the FRU List View for each FRU includes:

◆ FRU:

• CTP (Control Processor).

• FAN (fan module).

• PWR (power supply module).

The CTP is an internal component; if it fails completely, the entire switch

must be replaced.

◆ Position — Slot position of FRU in the unit relative to identical

FRUs also installed in the unit.

There are four fan modules (0–3), one CTP subsystem (0), and two

power supplies (0 and 1), and 32 port positions (3–31).

◆ Status:

• Active — Always appears unless the FRU has failed.

• Failed — Appears if the FRU is not functional.

◆ Part Number — Part number of the FRU.

◆ Serial Number — Serial number of the FRU.
