Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

108 Upgrade and Maintenance Manual RX1330 M1
Power supply
Ê Install the power supply units as described in section "Installing a hot-plug
power supply unit" on page 98.
6.3.4.4 Concluding steps
Ê "Reassembling" on page 52
Ê "Connecting the server to the mains" on page 55
Ê "Switching on the server" on page 57
Ê "Resuming BitLocker functionality" on page 84
6.4 Converting a standard power supply to a
redundant power supply
The standard power supply can be replaced by a redundant power supply. The
redundant power supply consists of up to two power supply units (slide-in units).
The upgrade kit contains only one power supply unit (for power supply
redundancy the second power supply unit must be additionally ordered).
The upgrade kit for the redundant power supply consists of the following parts:
– PSU cage with power distribution board
– two power cables
– one hot-plug power supply unit
– dummy cover (if only one power supply unit is installed, you have to install
the dummy cover in the second bay)
– several screws
– one fan module
Field Replaceable Unit
(FRU)
Hardware: 20 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
