V CAUTION!
Please note that you can only set the ATD flag. Resetting the ATD flag
using the Chassis ID Prom Tool is not possible!
5.2.17 Configuring LAN teaming
Use ServerView Operations Manager to obtain detailed information on existing
LAN teams:
Ê In ServerView Operations Manager Single System View select System Status
from the Information / Operation menu.
Ê Under Network Interfaces select LAN Teaming.
Ê The Network Interfaces (Summary) overview shows all configured LAN teams
and their components. Choose a LAN team to display further details:
– LAN Team Properties: Properties of the selected LAN team
– LAN Team Statistics: Available statistics about the selected LAN team
I For more detailed information, refer to the "ServerView Operations
Manager - Server Management" user guide.
5.2.17.1 After replacing / upgrading LAN controllers
Please note when re-using a replaced LAN controller:
Ê Confirm with the customer whether the LAN controller you have replaced
has been used as part of a LAN teaming configuration.
Ê If LAN teaming has been active, you will need to restore the configuration
using the LAN driver utility after replacing the LAN controller.
Ensure that the controllers have been assigned as primary or secondary
according to your requirements.
I For details, refer to the relevant LAN driver manual.
The ATD option can only be ordered from the manufacturer as
a factory preset. To find out if your server is ATD-enabled,
check for the ATD logo on the identification rating plate.
For further information on Cool-safe
®
Advanced Thermal
Design (ATD), please refer to your server’s operating manual.
