274 Upgrade and Maintenance Manual RX1330 M1
System board and components
Destroying the defective iRMC microSD card
V CAUTION!
The iRMC microSD card contains customer information. After replacing
the iRMC microSD card, hand the defective card over to the customer. If
the customer requests disposal of the defective iRMC microSD card,
proceed as follows:
Ê Using a pair of side-cutting pliers, cut the iRMC microSD card in half.
14.5.2.3 Concluding steps
Ê Install the riser module 1 as described in section "Installing a riser module"
on page 60.
Ê "Reassembling" on page 52
Ê "Connecting the server to the mains" on page 55
Ê "Switching on the server" on page 57
14.5.3 Replacing the iRMC microSD card
14.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê Remove the riser module 1 as described in section "Removing a riser
module" on page 58.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: a pair of side-cutting pliers

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
