Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

172 Upgrade and Maintenance Manual RX1330 M1
Expansion cards and backup units
Ê "Resuming BitLocker functionality" on page 84
9.4.2 Removing an expansion card
9.4.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 63
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê Remove the corresponding riser module as described in section "Removing
a riser module" on page 58.
9.4.2.2 Removing the expansion card
Ê If necessary, disconnect the cables from the expansion card.
Figure 107: Removing the expansion card - example riser module 1
Ê Pull out the expansion card from the riser card slot.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
