12.1 Basic information
You can install one 5.25-inch slimline optical disk drive (ODD). The installation
bay depends on the 2.5-inch or 3.5-inch HDD configuration.
The proceeding for installing/removing is identic except the routing of the cables
and the depending ODD power connector on the system board (see section
"Onboard connectors" on page 300).
3.5-inch HDD configuration
Figure 151: Position of the ODD bay - example 3.5-inch HDD configuration
Figure 152: Routing ODD cables - example 3.5-inch HDD configuration
