Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

210 Upgrade and Maintenance Manual RX1330 M1
Main memory
Figure 140: Installing a memory module
Ê Carefully press the memory module into the memory slot (1) until the
securing clips on both sides of it engage (2). Notice the coding (see circle).
10.2.4 Concluding steps
Ê "Reassembling" on page 52
Ê "Connecting the server to the mains" on page 55
Ê "Updating or recovering the system board BIOS and iRMC" on page 71
Ê "Enabling SVOM boot watchdog functionality" on page 78
Ê "Switching on the server" on page 57
Ê "Resuming BitLocker functionality" on page 84
10.3 Removing a memory module
10.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 63
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
