98 Upgrade and Maintenance Manual RX1330 M1
Power supply
6.3.1.3 Installing a hot-plug power supply unit
Figure 28: Folding up the handle
Ê Push the handle of the power supply unit halfway upward in the direction of
the arrow.
Figure 29: Installing the hot-plug power supply unit
Ê Push the power supply unit into its bay (1) as far as it will go until the locking
latch snaps in place.
Ê If applicable, fold down the handle on the power supply unit (2).
I Make sure that the power supply unit engages correctly in the bay and is
locked in position. This is the only way to prevent the power supply unit
from sliding out of its bay and being damaged during transportation.

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
