Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

216 Upgrade and Maintenance Manual RX1330 M1
Processor
Ê Remove the residual thermal paste from the underside of the heat sink and
the surface of the processor.
Ê Clean the underside of the heat sink and the surface of the processor using
a lint-free cloth.
11.2.3 Removing the defective processor
Figure 143: Opening the lever
Ê Press down the lever (1) and unhook it.
Ê Open the lever (2).
Figure 144: Opening the holder
Ê Take the holder by the small grip (1) and open it (2).

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
