Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

152 Upgrade and Maintenance Manual RX1330 M1
Fans
8.1.1 Numbering of the fan modules
Figure 85: Numbering of the fan modules
8.2 Replacing a defective fan module
8.2.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Locating the defective component" on page 45
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
