Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

RX1330 M1 Upgrade and Maintenance Manual 95
Power supply
6.2.1.3 Installing the new standard power supply unit
Figure 24: Inserting the standard power supply unit
Ê Insert the power supply unit into the bay (1).
Ê Push the power supply unit toward the adapter plate (2).
Ê Fasten the power supply unit with two screws in the chassis (3).
Ê Attach the power supply unit with two screws to the adapter plate (see figure
22).

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
