RX1330 M1

Upgrade and Maintenance Manual 199

Expansion cards and backup units

9.5.4.3 Disconnecting the FBU cable from the FBU

Figure 135: Disconnecting the FBU cable from the FBU

Ê Disconnect the FBU cable from the FBU.

9.5.4.4 Removing the FBU from the holder

Figure 136: Removing the FBU from the holder

Ê Pull the FBU at a slight angle out of the holder.
