Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

262 Upgrade and Maintenance Manual RX1330 M1
System board and components
Ê "Getting access to the component" on page 47
Ê Remove the riser module 1 as described in section "Removing a riser
module" on page 58.
14.4.1.2 Installing the TPM
Figure 193: TPM installation kit
Figure 194: Position on the system board
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
