Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

RX1330 M1 Upgrade and Maintenance Manual 147
Hard disk drives / solid state drives
7.3.4.2 Removing the defective 3.5-inch HDD module
Ê Remove the HDD module as described in section "Removing a 3.5-inch
HDD module" on page 145.
7.3.4.3 Installing the new 3.5-inch HDD module
Ê Install the HDD module as described in section "Installing a 3.5-inch HDD
module" on page 143.
7.3.4.4 Concluding steps
Ê "Performing a RAID array rebuild" on page 85
7.3.5 Replacing the 3.5-inch HDD backplane
7.3.5.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 45
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê Release all HDD modules and pull them out a few centimeters, see section
"Removing a 3.5-inch HDD module" on page 145
I The HDD modules need not to be removed. But if you want to remove
them nevertheless, check if all HDD modules are uniquely identified
so that you can reinsert them into their original bays.
7.3.5.2 Removing the defective 3.5-inch HDD backplane
Ê Disconnect all cables from the HDD backplane.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
