46 Upgrade and Maintenance Manual RX1330 M1
Basic hardware procedures
Ê Inform the system administrator that the server will be shut down and put
offline.
Ê Terminate all applications.
Ê Perform the required procedures described in the preliminary steps of each
upgrade or maintenance task.
Ê Shut down the server.
I If the system is running an ACPI-compliant operating system,
pressing the On / Off button will perform a graceful shutdown.
Ê Switch on the ID indicator on the front and rear connector panels of the
server as described in section "Locating the defective server" on page 43.
4.3 Disconnecting the server from the mains
Standard power supply
Figure 2: Unlocking the cable tie of a standard power supply unit
Ê Pull out on the locking lever on the cable tie (1) and loosen the loop (2).
Ê Disconnect the power cord from the power supply unit and remove it from
the cable tie.
햲
햳

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
