Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

RX1330 M1 Upgrade and Maintenance Manual 283
15 Cables
15.1 Overview cables
No. Part number Description From - to
C1 T26139-Y4015-V301 CBL FRONT_PANEL System board to front panel
C2 T26139-Y3959-V301 CBL_HDD_2.5_POWER System board to HDD
backplane 1
C3 T26139-Y3990-V301 CBL_ODD_Power System board to ODD power
C4 T26139-Y4028-V103 CBL SATA 530 System board to ODD data
C5 T26139-Y3994-V301 CBL_Front_VGA System board to Front VGA
C6 T26139-Y4015-V601 CBL_OOB_HDD_2BP System board to HDD
backplane 1 and 2
C7 T26139-Y3999-V501 CBL_FRONT_USB System board to front USB
C8 T26139-Y3964-V301 CBL_4HDD_DATA3.5 System board or RAID card
3.5-inch HDD backplane
C9 T26139-Y4041-V1 CBL_PDB_POWER System board to power
distribution board
C10 T26139-Y3956-V3 CBL_PDB_SIDEBAND System board to power
distribution board
C11 T26139-Y4040-V2 CBL 4HDD SAS 2.5 RAID card to 4x 2.5-inch HDD
backplane
C12 T26139-Y4040-V3 CBL 4HDD SAS 2.5 RAID card to 4x 2.5-inch HDD
backplane, L-shape
C13 T26139-Y3959-V351 CBL_HDD_3.5_POWER From System board to 3.5-
inch HDD backplane
C14 T26139-Y3959-V302 CBL PWR HDD 10X2.5 From System board to 10x
2.5-inch HDD backplane
C15 T26139-Y4042-V2 CBL FLEXP 22PL 600 System board to front panel
on QRL
(The front panel on QRL and
the front panel cable are
combined in one spare part.)
C16 T26139-Y3987-V1 LTG IBBU 700 BBU to RAID card
C17 T26139-Y4032-V1 CBL FBU02 620 FBU to RAID card
C18 T26139-Y4040-V9 CBL HOST-BP 540 Cougar4 to 4x 2.5-inch HDD
backplane, L-shape

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
