Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

Upgrade and Maintenance Manual RX1330 M1
Contents
7.3.5 Replacing the 3.5-inch HDD backplane . . . . . . . . . . . . . 147
7.3.5.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 147
7.3.5.2 Removing the defective 3.5-inch HDD backplane . . . . . . 147
7.3.5.3 Installing the new 3.5-inch HDD backplane . . . . . . . . . 148
7.3.5.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 149
8 Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
8.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 151
8.1.1 Numbering of the fan modules . . . . . . . . . . . . . . . . . 152
8.2 Replacing a defective fan module . . . . . . . . . . . . . . 152
8.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 152
8.2.2 Removing the defective fan module . . . . . . . . . . . . . . 153
8.2.3 Installing the new fan module . . . . . . . . . . . . . . . . . . 154
8.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 155
9 Expansion cards and backup units . . . . . . . . . . . . . 157
9.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 158
9.1.1 Equipping the PCIe slots . . . . . . . . . . . . . . . . . . . . 158
9.2 Handling slot brackets . . . . . . . . . . . . . . . . . . . . 161
9.2.1 Installing a slot bracket . . . . . . . . . . . . . . . . . . . . . 161
9.2.2 Removing a slot bracket . . . . . . . . . . . . . . . . . . . . 163
9.2.2.1 Removing the slot bracket . . . . . . . . . . . . . . . . . . 163
9.3 Handling SFP+ transceiver modules . . . . . . . . . . . . . 164
9.3.1 Installing SFP+ transceiver modules . . . . . . . . . . . . . . 164
9.3.2 Removing an SFP+ transceiver module . . . . . . . . . . . . 167
9.4 Expansion cards and riser cards . . . . . . . . . . . . . . . 170
9.4.1 Installing an expansion card . . . . . . . . . . . . . . . . . . 170
9.4.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 170
9.4.1.2 Removing the slot cover . . . . . . . . . . . . . . . . . . . 170
9.4.1.3 Installing the expansion card . . . . . . . . . . . . . . . . 171
9.4.1.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 171
9.4.2 Removing an expansion card . . . . . . . . . . . . . . . . . . 172
9.4.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 172
9.4.2.2 Removing the expansion card . . . . . . . . . . . . . . . . 172
9.4.2.3 Installing the slot cover . . . . . . . . . . . . . . . . . . . 173
9.4.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 173

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
