Fujitsu PRIMERGY RX1330 M1 Upgrade And Maintenance Manual

190 Upgrade and Maintenance Manual RX1330 M1
Expansion cards and backup units
Ê Install a RAID controller as described in section "Installing an expansion
card" on page 170.
Figure 126: Connecting the BBU cable to the RAID controller
Ê Connect the BBU cable to the RAID controller.
V CAUTION!
● Make sure that the connector side with the three dots is on the top.
Otherwise you risk short-circuits.
● Do not connect the cable using excessive force, the connector is
weak.

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
