248 Upgrade and Maintenance Manual
RX1330 M1
Front panel
Figure 178: Removing the front panel on QRL (A)
Ê Remove the two screws (see circles).
Figure 179: Removing the front panel on QRL (B)
Ê Remove the front panel.
Ê Pull the front cable out of the opening.
