RX1330 M1 Upgrade and Maintenance Manual 301
Appendix
No. Print Description
1 UFM Connector for optional USB Flash Module (UFM)
2 P30 Power supply connector (redundant power supply
only)
3 FRONT PANEL Front panel connector (front panel module)
4 PWR3 Power supply connector for ODD (2.5-inch HDD
configuration)
5 PC98 Power supply connector (standard power supply
only)
6 PWR2 Power connector for HDD backplane
7 PWR1 Power supply connector 12V
8 FAN5 Power connector for system fan 5
9 USB FRONT Front USB connector
10 FAN4 Power connector for system fan 4
11 FAN3 Power connector for system fan 3
12 FAN2 Power connector for system fan 2
13 FAN1 Power connector for system fan 1
14 PWR4 Power supply connector for ODD (3.5-inch HDD
configuration)
15 FRONT VGA Connector for optional front VGA
16 SMB4 OOB (Out Of Band) connector for HDD backplane
17 SATA 5 SATA connector for ODD
18 MLC SATA 1-4 SATA HDD connector
19 TPM Connector for optional TPM
20 FRONT PANEL Front panel connector (front panel on QRL)
21 micro SD iRMC microSD card

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
