RX1330 M1 Upgrade and Maintenance Manual 307
Appendix
Status indicators
Pos. Indicator Status Description
3 ID indicator
blue on
server has been highlighted using
ServerView Operations Manager, iRMC
web frontend or the ID button on the front
panel for easy identification
blue flashing local monitor off
4
CSS
indicator
off no critical event (CSS component)
orange on prefailure detected (CSS component)
orange
flashing
CSS component failure
5
Global
Error
indicator
off no critical event (non CSS component)
orange on prefailure detected (non CSS component)
orange
flashing
indicates a failure of a non CSS
component.
Reasons for a failure may be:
– over temperature measured by one of
the sensors
– sensor is defective
– CPU error
– software detected an error
6
HDD / SSD
activity
indicator
green on data access in progress
7
Power-on
indicator
off
is off in the following case:
– the system is in power-off mode but
connected to the mains (AC
connected)
green on
is on in the following cases:
– the system has been switched on and
is in power-on delay
– the system is powered on and in
normal operation (S0)
flashes slowly
(1/2 Hz)
iRMC S4 is not ready

Fujitsu PRIMERGY RX1330 M1 Specifications

General

Number of Processors	1
Memory Slots	4
Maximum Memory	32 GB
Form Factor	1U Rack
Processor	Intel Core i3 product family Intel Pentium product family
CPU Family	Intel Xeon
Memory Type	DDR3 UDIMM
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4
RAID	0, 1, 5, 10
RAID Controller	Optional
Network	2 x Gigabit Ethernet
Operating System Support	Windows Server, Red Hat Linux, SUSE Linux
