Indicators on the hot-plug HDD module
Figure 232: Indicators on the hot-plug HDD module
Pos. Indicator Status Description
1 HDD BUSY
off HDD inactive
green on
HDD in active phase (drive active, drive
being accessed)
2 HDD FAULT
off no HDD error
orange on
HDD faulty or rebuild stopped (drive
defective/needs replacing, a rebuild
process was stopped or the HDD
module is not correctly inserted)
orange slow
flashing
HDD rebuild (the data is being restored
after changing a drive)
