142 Upgrade and Maintenance Manual
TX1330 M1
Hard disk drives / solid state drives
7.3.6.2 Removing the defective 3.5-inch HDD SAS backplane
Figure 58: Disconnecting cables
Ê Disconnect the cables from the SAS backplane:
– (1) power cable from connector "x7"
– (2) SAS/SATA data cable from connector "x1"
