Fujitsu Server PRIMERGY TX1330 M1 - PSU Indicator (Only Hot-Plug Psus)

328 Upgrade and Maintenance Manual TX1330 M1
Appendix
17.2.1.5 PSU indicator (only hot-plug PSUs)
Figure 229: PSU indicator
Indicator Status Description
1
PSU
operating
status
green on
Server is switched on and functioning
properly
green flashing
Server is switched off, main voltage is
present (Standby mode)
orange on
PSU failure (over / under voltage, over
temperature or fan failure)
orange flashing Overload warning
