TX1330 M1 Upgrade and Maintenance Manual 111
Power supply
6.3.2.3 Installing the dummy cover
Figure 37: Installing the dummy cover
Ê Insert the dummy cover into the empty bay with the impressed arrow symbol
facing to the left (see circle).
Ê Push the dummy cover into its bay until it locks in place.
V CAUTION!
Always install dummy covers into unused bays to comply with
applicable EMC regulations and satisfy cooling requirements.
6.3.3 Replacing a hot-plug power supply unit
V CAUTION!
● When replacing a power supply unit in a non-redundant PSU
configuration, the server must be switched off first.
● Ensure to replace a defective power supply unit by a new one of the
same type.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
