52 Upgrade and Maintenance Manual TX1330 M1
Basic hardware procedures
4.4.1.4 Removing the rack front cover
I You remove the rack front cover when installing/removing accessible
drives.
Figure 6: Removing the ID card (rack server)
Ê Remove the ID card from the server.
Figure 7: Removing the rack front cover (A)
Ê Remove two screws from the side brackets on either side of the rack
mounting frame (see circles).

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
