9.2 Handling slot brackets
9.2.1 Installing a slot bracket
I Use the following slot bracket for the ModularRAID controllers based on
LSI MegaRAID:
– Full height bracket not-perforated
Figure 76: Perforated and non-perforated slot brackets
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
1 Full height bracket non-perforated
2 Full height bracket perforated
3 Low profile bracket perforated
