TX1330 M1 Upgrade and Maintenance Manual 161
Expansion cards and backup units
I For the latest information on supported expansion cards, refer to your
server’s hardware configurator available online at the following address:
for the EMEA market:
http://ts.fujitsu.com/products/standard_servers/index.htm
for the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/system/
Max pcs
per system
Slot no
1 2 3 4
SAS/RAID controller
D2607 SAS RAID Controller
(LSI SAS 2008 based)
1---1
D2616 SAS RAID Controller
(LSI SAS 2108 based)
1---1
D3116 SAS RAID Controller PCIe Gen 3
(LSI SAS 2208 V3 based)
1---1
D2627 PSAS CP200i Host Bus Adapter
(LSI SAS 2008 based)
1 -213
Ethernet controller
Single Port Gigabit Desktop Adapter PRO/1000 CT 2 1 2 3 -
Single Port Gigabit Server Adapter PRO/1000 PF 2 1 2 3 -
Dual Port Gigabit Ethernet Controller D3035 2 - 1 2 3
Quad Port Gigabit Ethernet Controller D3045 2 - 1 2 3
Dual Port 10 Gb Ethernet Controller D2755 1 - - 1 2
Dual Port 10 GBase-T Server Adapter X540-T2 1 - - 1 2
Miscellaneous
Nvidia NVS300 Graphics Card 1 1 2 - -
Riser Card for 32-bit PCI cards with PCI adapter
board
11---

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
