TX1330 M1 Upgrade and Maintenance Manual 231
Accessible drives
12.2 Installing accessible drives
12.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 69
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing the rack front cover" on page 52 (rack server) or "Removing the
front cover" on page 56 (tower server)
I The front cover only needs to be removed in order to remove or install
accessible drive dummy covers.
Sequence Accessible drive Bay Max. no.
1
Optical disk drive or
slimline optical disk drive
Bay 1 1
2 Backup drive LTOx
Bay 3, if occupied: bay 2
or bay 1
1
3 Backup drive DAT
Bay 3, if occupied: bay 2
or bay 1
2
4 Backup drive RDX
Bay 3, if occupied: bay 2
or bay 1
2
Table 7: Accessible drive mounting sequence
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for installing mounting brackets)

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
