TX1330 M1 Upgrade and Maintenance Manual 257
System board and components
14.3 USB Flash Module (UFM)
14.3.1 Installing the UFM
14.3.1.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 69
Ê "Disabling SVOM boot watchdog functionality" on page 70
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
14.3.1.2 Installing the UFM
Figure 161: UFM kit
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Software: 5 minutes
Tools: tool-less
1 USB Flash Module (UFM) 2 UFM spacer
3 UFM nylon screw

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
